Pogo Pin, 1Pin T/L 3.4mm W/H 2.6mm
303A-250918-002
Pogo Pin, 1Pin T/L 3.4mm W/H 2.6mm

A pogo pin or spring-loaded pin is a type of electrical connector mechanism. The conducting surface is gold plated which provides great corrosion resistance, enhances its mechanical strength and electrical conductivity.

Pogo pin combines the advantages of fine pitch, high current, and long lifetime that can be widely used in industrial, medical, and consumer applications.
MAIN FEATURES
*
Conclusion:
  • High Stroke
  • High Durability
  • Long Lifetime
  • Ease of Attaching
  • Stable Current Flow
*
Application:
  • Antenna
  • Board To Board Connection
  • Medical Device
  • Tracking Device
  • Portable Device
*
SPECIFICATION
ELECTRICAL
Current Rating1A
Voltage Rating12V
Contact Resistance50mΩ MAX. at Working Height(static state)
MECHANICAL
Durability10,000 Cycle
Spring Force110g±20% at Working Height
WARNING
Avoid arcing issuesThe adaptor starts to the power supply after the connector mated fully
Ensure the best usageOperate it based on the working height
NotedBased on the Drawing, shall not exceed the maximum allowed compress
DOWNLOAD
CATEGORYTITLESIZEFILE TYPEDOWNLOAD
Drawing303A-250918-002156 KBPDF: DrawingDownload
3D303A-250918-0025 KBRAR: 3D FileDownload
