Pogo Pin Right Angle Type, 2Pin Pitch 2.5mm T/L 5.3mm W/H 3.9mm
303B-351819-25-000
Pogo Pin Right Angle Type, 2Pin Pitch 2.5mm T/L 5.3mm W/H 3.9mm

A pogo pin or spring-loaded pin is a type of electrical connector mechanism. The conducting surface is gold plated which provides great corrosion resistance, enhances its mechanical strength and electrical conductivity.

Pogo pin combines the advantages of fine pitch, high current, and long lifetime that can be widely used in industrial, medical, and consumer applications.
MAIN FEATURES
*
Conclusion:
  • High Stroke
  • High Durability
  • Long Lifetime
  • Ease of Attaching
  • Stable Current Flow
*
Application:
  • Antenna
  • Board To Board Connection
  • Medical Device
  • Tracking Device
  • Portable Device
*
SPECIFICATION
ELECTRICAL
Current Rating1A
Voltage Rating12V DC
Contact Resistance50mΩ
Insulation Resistance100MΩ
Dielectric Withstanding Voltage500VAC
MECHANICAL
Spring Force120g±20% at 4.30 Working Height
Durability10,000 Cycles
ENVIRONMENTAL
Operating temperature range-40°C~+85°C
Storage temperature range-40°C~+85°C
SOLDER ABILITY
Recommended IR Reflow Temperature250°C
DOWNLOAD
CATEGORYTITLESIZEFILE TYPEDOWNLOAD
Drawing303B-351819-25-000199 KBPDF: DrawingDownload
