Pogo Pin, 4Pin Pitch 2.5mm T/L 5.0mm W/H 3.6mm
303B-361420-25-04
Pogo Pin, 4Pin Pitch 2.5mm T/L 5.0mm W/H 3.6mm

A pogo pin or spring-loaded pin is a type of electrical connector mechanism. The conducting surface is gold plated which provides great corrosion resistance, enhances its mechanical strength and electrical conductivity.

Pogo pin combines the advantages of fine pitch, high current, and long lifetime that can be widely used in industrial, medical, and consumer applications.
MAIN FEATURES
*
Conclusion:
  • High Stroke
  • High Durability
  • Long Lifetime
  • Ease of Attaching
  • Stable Current Flow
*
Application:
  • Antenna
  • Board To Board Connection
  • Medical Device
  • Tracking Device
  • Portable Device
*
DOWNLOAD
CATEGORYTITLESIZEFILE TYPEDOWNLOAD
Drawing303B-361420-25-04196 KBPDF: DrawingDownload
3D303B-361420-25-0438 KBRAR: 3D FileDownload
