| July 25, 2023 - ATTEND, a leading provider of advanced connectivity solutions, announces the introduction of the 114B Series Mini PCI and 119A Mini PCIe Connectors. These connectors, commonly used in small-form-factor devices, provide a standardized interface for adding expansion cards to computer systems.
ATTEND's 114B series Mini PCI interface employs a 32-bit, 33 MHz data bus, accommodating either 3.3V or 5V power connections. With 124 pins, this compact connector offers a compatible transfer rate of 133 MB/s. The 119A series Mini PCIe connector follows the PCI Express standard, providing a high-speed data transfer interface with one differential transmit pair and one differential receive pair. It facilitates either 1.5V or 3.3V power connections, with a total of 52 pins. Both Mini PCI and Mini PCIe connectors are used extensively for adding expansion cards such as Wi-Fi, Bluetooth®, mobile network, and SSD. Key Features Mini PCI connector - Available heights: 4.0 mm and 9.2 mm
- Compatible transfer rate of 133 MB/s for 32-bit, 33 MHz
- All-in-one retention latch on the connector
Mini PCIe connector - Height range: 4.0 mm to 9.9 mm
- Optional accessories include a single fixation latch, two dual fixation latches, or two nuts with two screws
- The connector and latch are surface-mount devices
- Compatible PCI Express 1.0 x1 (250 MB/s) and PCI Express 2.0 x1 (500 MB/s)
Applications The 114B/119A Series Mini PCI and Mini PCIe Connectors are ideal for: - Box PCs
- Edge computing
- Industrial PCs
- Embedded systems
With the launch of the 114B/119A Series, ATTEND continues to provide innovative, high-quality solutions for today's technology-driven world.
For more information on ATTEND's 114B/119A Series Mini PCI and Mini PCIe Connectors, please visit www.attend.com.
Experience the future of expansion with ATTEND. Order now on Digi-Key
About ATTEND
ATTEND, based in Taiwan, has been dedicated to delivering comprehensive connectivity solutions to customers worldwide. Our product line includes a wide range of connectors and cables, such as memory card sockets, PCB card sockets, I/O connectors, and cable assemblies. Our products find applications across diverse sectors, including industrial, networking, transportation, and consumer electronics. By actively engaging with our client's businesses, we offer innovative connectivity solutions that empower them to develop cutting-edge products and maintain a competitive edge.
|
