Compact 7A and IP67-rated 30A connector options support rechargeable battery systems across portable and industrial equipment.
ATTEND, a leading provider of advanced connectivity solutions, has introduced its new Blade Battery Connector Series, comprising 13 products designed for rechargeable battery systems. Featuring compact PCB-level interfaces and waterproof high-current connections, the new series addresses increasing demands for power capacity, mechanical durability, and installation flexibility in battery-powered equipment.
Two product families address distinct design requirements: 304A Blade Battery Connectors for space-constrained applications and 304B Waterproof Blade Battery Connectors for higher-current systems requiring IP67 protection. Multiple contact configurations and mounting options support battery integration across portable electronics, industrial equipment, robotics, e-mobility, unmanned aerial vehicles (UAVs), and other rechargeable devices.
Compact Blade Battery Connectors – 304A Series
304A Blade Battery Connectors feature a compact 2.5 mm pitch, 7A/30VDC rating, multiple pin-count and mounting options, and up to 4,000 mating cycles for reliable battery connections in portable devices, medical equipment, and docking systems.
Waterproof High-Current Battery Connectors – 304B Series
304B Waterproof Blade Battery Connectors offer IP67 protection, 30A/60VDC power ratings, multiple power and signal contact configurations, panel-mount and vertical DIP options, and up to 3,000 mating cycles for reliable battery connectivity in robotics, UAVs, e-mobility, and industrial equipment.
“Battery-powered equipment must balance space constraints, increasing power demands, and repeated mating requirements,” said Leon Hung, Product Manager at ATTEND Technology. “With compact and waterproof high-current options in our new Blade Battery Connector Series, ATTEND provides engineers with greater flexibility when integrating rechargeable battery systems into different equipment designs.”
Key Features
- 2.5 mm pitch for space-constrained PCB designs
- 7A current rating and 30VDC voltage rating
- Multiple pin-count and connector-height options
- Male vertical, male right-angle, and female versions
- Up to 4,000 mating cycles
- IP67-rated dust and water protection
- 30A power contacts and 5A signal contacts
- 6 power or 4 power + 9 signal contact configurations
- Male and female versions with panel-mount and vertical DIP options
- Up to 3,000 mating cycles
Technical Specifications
- Pitch: 2.5 mm
- Current rating: 7A
- Voltage rating: 30VDC
- Mating durability: up to 4,000 cycles
- Mounting options: male vertical, male right-angle, and female configurations
- Current rating: 30A power / 5A signal
- Voltage rating: 60VDC
- Contact configurations: 6 power or 4 power + 9 signal
- Ingress protection: IP67
- Mating durability: up to 3,000 cycles
- Mounting options: panel-mount and vertical DIP
Applications
- Industrial Handheld Devices and Tablets
- Battery Docking and Charging Systems
- Portable Test and Measurement Equipment
- Medical and Healthcare Devices
- Robotic Docking Systems
- Battery Management Systems (BMS)
- Industrial Robotics and AGVs/AMRs
- UAVs and Industrial Drones
- Electric Bicycles and Scooters
- Battery-Powered Tools
- Portable Power Systems
Product Lineup
- 304A Blade Battery Connectors — Compact 2.5 mm pitch connectors rated at 7A, featuring multiple PCB mounting configurations for rechargeable battery applications.
- 304B Waterproof Blade Battery Connectors — IP67 high-current connectors with 30A power contacts, combined power-and-signal options, and panel-mount or vertical DIP configurations.
