Plastic D Size Conn.,Solder Pin, F Skt F
圖號:227D-AFF0
Drawing Number:227D-AFF0
D Size Conn.,Solder Pin, F Skt F, Field Installable Lock Bayonet
ATTEND’s plastic circular sealed connectors cover an extensive range which includes A/ B/ C/ D size connectors that support customers look for solutions based on the industry-proven market standard. Waterproof performance is for IPX7/IPX8.
Circular connector generally use in industrial automation, Ethernet system, intelligent transportation system, Traffic safety system and outdoor devices for decades.
D Size Conn.,Solder Pin, F Skt F, Field Installable Lock Bayonet
ATTEND’s plastic circular sealed connectors cover an extensive range which includes A/ B/ C/ D size connectors that support customers look for solutions based on the industry-proven market standard. Waterproof performance is for IPX7/IPX8.
Circular connector generally use in industrial automation, Ethernet system, intelligent transportation system, Traffic safety system and outdoor devices for decades.
Share:
功能介紹
FEATURES:
●Quick-Coupling with positive lock
●Operating temperature range: -40°C~85°C
●High shock and vibration capabilities
●Rugged construction
●IP 67 in sealed condition
APPLICATION:
●Power
●IIOT
●Industry
●Power
●IIOT
●Industry
Part Number | Pin Assignment | Pin Count | Current Rating |
---|---|---|---|
227D-04F01 | 4Pin | 20A | |
227D-05F01 | 5Pin | 20A | |
227D-07F01 | 7Pin | 20A |
Part Number | Pin Assignment | Pin Count | Current Rating |
---|---|---|---|
227D-18F01 | 18Pin | 5A |
規格介紹
Current Rating | 5A/ 20A per pin |
---|---|
Contact Resistance | 10mΩ |
Insulation Resistance | 100MΩ |
Dielectric Withstanding Voltage | 500VAC |
Durability | 1,000 Cycle |
---|
Operating temperature range | -40°C~+85°C |
---|---|
Storage temperature range | -40°C~+85°C |
