Micro SD with SIM Card Socket, Push-Push Type
112G-TA00-R
Micro SD with SIM Card connector, Push-Push Type w/switch, GF
A well-known integrated circuit module which mainly used to securely store the international mobile subscriber identity (IMSI) number and its related key for identifying and authenticate subscribers on mobile or embedded devices. The connector combine with Micro SD card socket could be effecting save the PCB space.
A well-known integrated circuit module which mainly used to securely store the international mobile subscriber identity (IMSI) number and its related key for identifying and authenticate subscribers on mobile or embedded devices. The connector combine with Micro SD card socket could be effecting save the PCB space.
Share:
功能介紹
APPLICATION:
- IIOT
- WIFI Module
- Smart Meter
- LTE Router
- IPC / POS
- Vehicle Tracking
規格介紹
| Current | 0.5A Max |
|---|---|
| Voltage | 100V AC |
| Contact Resistance | 40mΩ |
| Voltage Proof | 500V AC |
| Insulation Resistance | 1,000MΩ |
| Card Insertion/Withdraw Force | 13.8N Max |
|---|---|
| Push-In Strength | 19.6N |
| Durability | 10,000 Cycles |
| Insulator | LCP Black |
|---|---|
| Shell | SUS304 |
| Contact | Copper Allor |
| Contact area | Gold Flash Plating |
下載
| 類別 | 標題 | 大小 | 文件類型 | 下載 |
|---|---|---|---|---|
| 圖面 | 112G-TA00-R | 262 KB | PDF: 工程用圖面 |  |
| 3D | 112G-TA00-R | 988 KB | RAR: 3D檔 | |
