M12 A Code, Plug, Male, Overmold with cable

216A-XXMO0

M12 A Code, Plug for Cable, Male Pins, Overmold with cable

ATTEND’s M-series circular connectors cover an extensive range which includes M5/8/12/23 connectors that support customers look for solutions based on the industry-proven market standard. Circular connector generally use in industrial automation, Ethernet system, intelligent transportation system, Traffic safety system and outdoor devices for decades.

功能介紹

The most type of all series, it offers support for high power and high frequency. It is considered the best option for high speed signal transmission and power feeding solution for industrial and rugged applications under more demanding environments thanks to its IP67 rating and robustness. In addition, its coding defined under the standards coding helps preventing incorrect mating connection.

Product Specification Comparison Table
Part Number	Pin Assignment	Pin Count
216A-03MO0		3Pin
216A-04MO0		4Pin
216A-05MO0		5Pin
216A-06MO0		6Pin

Product Specification Comparison Table
Part Number	Pin Assignment	Pin Count
216A-08MO0		8Pin
216A-10MO0		10Pin
216A-12MO0		12Pin

規格介紹

ELECTRICAL
2~4 Pin Current Rating	4A
2~4 Pin Voltage Rating	250V

5 Pin Current Rating	4A
5 Pin Voltage Rating	60V

6~8 Pin Current Rating	2A
6~8 Pin Voltage Rating	30V

9~12 Pin Current Rating	1.5A
9~12 Pin Voltage Rating	30V

ENVIRONMENTAL
Operating temperature range	-40°C~+85°C
Waterproof Level	IP67

下載

類別	標題	大小	文件類型
圖面	216A-05MO0	182 KB	PDF: 工程用圖面
3D	216A-05MO0	2031 KB	RAR: 3D檔
圖面	216A-08MO0	77 KB	PDF: 工程用圖面
3D	216A-08MO0	601 KB	RAR: 3D檔
圖面	216A-10MO0	72 KB	PDF: 工程用圖面
3D	216A-10MO0	2494 KB	RAR: 3D檔
圖面	216A-04MO0	70 KB	PDF: 工程用圖面
3D	216A-04MO0	422 KB	RAR: 3D檔
圖面	216A-03MO0	48 KB	PDF: 工程用圖面
圖面	216A-06MO0	75 KB	PDF: Drawing
圖面	216A-12MO0	74 KB	PDF: 工程用圖面
3D	216A-12MO0	1611 KB	RAR: 3D檔
規格書	216Series Spec	396 KB	PDF:規格書
