Automotive USB4 Type C Cable, Male-Male, 1M, Black
US-CPCP-10003
Automotive USB4 type C cable, Male to Male, L=1M, black

ATTEND’s Automotive USB Type C Connectivity System delivers robust power, high-speed data, and Automotive-grade durability to meet the needs of automation, intelligent transport, AGVs, transport vehicles, diagnostics and Automotive aftermarket upgrades. Designed to meet the stringent requirements of USCAR-2 standard design, it performs reliably in harsh environments.
Share:
MAIN FEATURES
Automotive USB4 Type CA

  • Compliant with USB4 Gen3 standard, supporting data transfer rates up to 40 Gbps.

  • Supports PD 3.1 standard up to 5A/48V (240W) power delivery

  • USCAR-2 compliant design ensures reliable connectivity under severe vibration and shock environments.

  • Constructed with UL94 V-0 high-temp plastics and gold-plated contacts for reliability.

  • TPE cable jacket offers resistance to oils, acids, and chemicals.

  • Wide operation temperature range from -40°C to +105°C.

APPLICATIONS
In-Vehicle Infotainment

  • In-Vehicle Infotainment

  • Rear Seat Entertainment

  • Industrial HMI Panels

  • Intelligent Transport Systems

  • Autonomous Vehicles

  • Embedded USB-C Modules

  • USB Charger Module

  • USB Media Hub

SPECIFICATION
ELECTRICAL
Current Rating5A
Voltage Rating48V
Contact Resistance40mΩ Max. Initial, 15mΩ Max. after
Insulation Resistance100MΩ Min.
Withstanding VoltageAC-1000V/1min
Applicable StandardsUSB 4.0 Gen 3
USB Type-C, USB PD Revision 3.0
Max Data Transfer Rate40 Gbps
MECHANICAL
Length1M
ConnectorUSB C Male,USB C Male
Side A AngleStraight
Side B AngleStraight
Materials / ColorsPBT/Black
Mating Force45N Max.
Number of Positions24 positions
Un-mating Force10N~75N
Un-mating Force Lock110N Min.
Durability10 cycles
Weight (g)52.7g
ENVIRONMENTAL
Operating temperature range-40°C to 105°C
DOWNLOAD
CATEGORYTITLESIZEFILE TYPEDOWNLOAD
DrawingUS-CPCP-10003609 KBPDF: DrawingDownload
