Nano SIM Socket, Push-Pull Type, with Peg
115U-A004
Nano SIM Socket, 6 Pin, Push Pull Type, 1.5H, G/F, with Peg, Reel
ATTEND’s Nano SIM Socket provides stable SIM card connectivity with a push-pull mechanism for easy operation and a peg for added stability. Ideal for mobile devices, IoT applications, and industrial systems, this socket is designed for lasting performance in demanding environments. ATTEND’s commitment to superior design and high-quality materials ensures reliable connectivity, making it the perfect choice for robust solutions.
ATTEND’s Nano SIM Socket provides stable SIM card connectivity with a push-pull mechanism for easy operation and a peg for added stability. Ideal for mobile devices, IoT applications, and industrial systems, this socket is designed for lasting performance in demanding environments. ATTEND’s commitment to superior design and high-quality materials ensures reliable connectivity, making it the perfect choice for robust solutions.
Share:
MAIN FEATURES
SPECIFICATION
| Current Rating | 0.5A per pin |
|---|---|
| Voltage Rating | 10V DC |
| Contact Resistance | 100mΩ Max. |
| Insulation Resistance | 1000MΩ |
| Dielectric Withstanding Voltage | 500VAC |
| Durability | 1,500 cycles |
|---|---|
| Contact Normal Force | 0.3N min. per pin |
| Operating temperature range | -40°C~+85°C |
|---|---|
| Storage temperature range | - 40°C~+85°C |
| Recommended IR Reflow Temperature | 260°C |
|---|
DOWNLOAD
| CATEGORY | TITLE | SIZE | FILE TYPE | DOWNLOAD |
|---|---|---|---|---|
| Drawing | 115U-A004 | 95 KB | PDF: Drawing |  |
| 3D | 115U-A004 | 196 KB | RAR: 3D File | |
