HDMI 2.1 A Type Connector, Flank DIP Type, w/o Flange
206A-DA01
2.1 HDMI Connector, A Flank DIP Type, w/o Flange, G/F
HDMI stands for High Definition Multimedia Interface. It is capable of sending higher quality information to a device than its analog counterparts. The information which sent over via HDMI is uncompressed digital video/audio data, because it could transfer the video/audio signal in a single cable same time, that could save PCB design space effectively.
HDMI stands for High Definition Multimedia Interface. It is capable of sending higher quality information to a device than its analog counterparts. The information which sent over via HDMI is uncompressed digital video/audio data, because it could transfer the video/audio signal in a single cable same time, that could save PCB design space effectively.
Share:
SPECIFICATION
| Current Rating | 0.5A per pin |
|---|---|
| Contact Resistance | 30mΩ |
| Insulation Resistance | 100 MΩ |
| Dielectric Withstanding Voltage | 500VAC |
| Durability | 10,000 Cycle |
|---|---|
| Insertion Force | 4.5kgf |
| Extraction Force | 1kgf~4kgf |
DOWNLOAD
| CATEGORY | TITLE | SIZE | FILE TYPE | DOWNLOAD |
|---|---|---|---|---|
| 3D | 206A-DA01 | 266 KB | RAR: 3D File |  |
| Drawing | 206A-DA01 | 106 KB | PDF: Drawing | |
