QSFP Cage 2x1 Press Fit Type w/Connector 15u"
223C-2103
QSFP Cage 2x1 Press Fit Type w/Connector 15u"

The small form-factor pluggable (SFP) is a compact, hot-pluggable network interface module used for both telecommunication and data communication applications. ATTEND offers a variety of SFP/SFP+/QSFP cage types that support 1Gbps to 40Gbps data rates for Gigabit Ethernet and Optical Fiber applications and compatible industry-wide standard SFP/ SFP+/ QSFP modules for your application usage to fit your high-speed networking request.
SPECIFICATION
ELECTRICAL
Current Rating0.5A
Voltage Rating30V AC/DC
Contact Resistance80mΩ Max
Insulation Resistance1000MΩ
Differential Impedance Voltage300V
MECHANICAL
Mating Force60N Max.
UN-Mating Force30N Max.
Contact Normal Force0.5N Min.
Durability250 cycles
ENVIRONMENTAL
Operating temperature range-40℃~+85℃
Storage temperature range-20℃~+85℃
DOWNLOAD
CATEGORYTITLESIZEFILE TYPEDOWNLOAD
Drawing223C-2103224 KBPDF: DrawingDownload
3D223C-21032153 KBRAR: 3D FileDownload
