M12 A Code, Plug, Male, Overmold with cable
M12 A Code, Plug for Cable, Male Pins, Overmold with cable

ATTEND’s M-series circular connectors cover an extensive range which includes M5/8/12/23 connectors that support customers look for solutions based on the industry-proven market standard. Circular connector generally use in industrial automation, Ethernet system, intelligent transportation system, Traffic safety system and outdoor devices for decades.
Panel Mount Ordering Instructions
Underwater Unmanned Vehicle
The most type of all series, it offers support for high power and high frequency. It is considered the best option for high speed signal transmission and power feeding solution for industrial and rugged applications under more demanding environments thanks to its IP67 rating and robustness. In addition, its coding defined under the standards coding helps preventing incorrect mating connection.
Product Specification Comparison Table
Part NumberPin AssignmentPin Count
             216A-03MO0             Pin Assignment3Pin
216A-04MO0Pin Assignment4Pin
216A-05MO0Pin Assignment5Pin
216A-06MO0Pin Assignment6Pin
Product Specification Comparison Table
Part NumberPin AssignmentPin Count
216A-08MO0Pin Assignment8Pin
216A-10MO0Pin Assignment10Pin
216A-12MO0Pin Assignment12Pin
2~4 Pin Current Rating4A
2~4 Pin Voltage Rating250V
5 Pin Current Rating4A
5 Pin Voltage Rating60V
6~8 Pin Current Rating2A
6~8 Pin Voltage Rating30V
9~12 Pin Current Rating1.5A
9~12 Pin Voltage Rating30V
Operating temperature range-40°C~+85°C
Waterproof LevelIP67
Drawing216A-05MO0182 KBPDF: DrawingDownload
3D216A-05MO02031 KBRAR: 3D FileDownload
Drawing216A-08MO077 KBPDF: DrawingDownload
3D216A-08MO0601 KBRAR: 3D FileDownload
Drawing216A-10MO072 KBPDF: DrawingDownload
3D216A-10MO02494 KBRAR: 3D FileDownload
Drawing216A-04MO070 KBPDF: DrawingDownload
3D216A-04MO0422 KBRAR: 3D FileDownload
Drawing216A-03MO048 KBPDF: DrawingDownload
Drawing216A-06MO075 KBPDF: DrawingDownload
Drawing216A-12MO074 KBPDF: DrawingDownload
3D216A-12MO01611 KBRAR: 3D FileDownload
Datasheet216Series Spec396 KBPDF:SpecDownload
