RJ45 8P8C, Straight PCB Type, Receptacle Waterproof, GF
222A-03001
RJ45 8P8C, Straight PCB Type, Receptacle Waterproof, GF
The sealed I/O connector enables use under the rugged environmental conditions, Through the potting of electronics in a compact plastic or metal housing with sealed connectors. Our sealed I/O series reaching the protection class IPX7, to ensure your digital information, voltages power can be safely continued transmission under a harsh environment.
The sealed I/O connector enables use under the rugged environmental conditions, Through the potting of electronics in a compact plastic or metal housing with sealed connectors. Our sealed I/O series reaching the protection class IPX7, to ensure your digital information, voltages power can be safely continued transmission under a harsh environment.
Share:
AVAILABLE ACCESSORIES
MAIN FEATURES
- Current rating: 1.5 A (with PCB/adapter type), 2.0 A (straight PCB type)
- Voltage rating: 125 V (with PCB/adapter type), 250 V (straight PCB type), AC/DC
- Waterproof level: IPX7
- High corrosion resistance (salt mist, sterilization, chemicals)
- Integrated kit can be applied to off-the-shelf RJ45 patch cords
- Operating temperature range: -40°C to +85°C
APPLICATION:
- Rugged environmental
- Outdoor usage
- Automotive
- Industrial
- Communication
- Factory automation
- Marine
SPECIFICATION
| Current Rating | 2A per pin |
|---|---|
| Voltage Rating | 250V AC/DC |
| Operating temperature range | -40°C~+85°C |
|---|---|
| Waterproof Level | IPX7 |
DOWNLOAD
| CATEGORY | TITLE | SIZE | FILE TYPE | DOWNLOAD |
|---|---|---|---|---|
| Drawing | 222A-03001 | 143 KB | PDF: Drawing |  |
| 3D | 222A-03001 | 478 KB | RAR: 3D File | |
| Drawing | 222A-03003 | 117 KB | PDF: Drawing | |
| 3D | 222A-03003 | 365 KB | RAR: 3D File | |
| Drawing | 222-0004 | 53 KB | PDF: Drawing | |
